Tektronix AFG3021C Function Generator 1CH, 25MHz
Tektronix AFG3021C Function Generator 1CH, 25MHz
Product Overview:
The Tektronix AFG3000C Series is a family of arbitrary/function generators covering sine waveform output from 10 MHz to 240 MHz across six bandwidth tiers and both single-channel and dual-channel configurations. The series produces twelve standard waveforms — sine, square, pulse, ramp, triangle, Sin(x)/x, exponential rise and decay, Gaussian, Lorentz, Haversine, DC, and noise — and supports user-defined arbitrary waveforms up to 128 K in length with 14-bit vertical resolution. Each unit features a 5.6 inch color TFT display, multi-language operation, and a highly stable timebase specified at ±1 ppm aging per year.
The datasheet identifies four application areas for the pre-owned AFG3000C Series: electronic test and design, sensor simulation, functional test, and education and training. Pulse waveforms support independently adjustable leading and trailing edge times, dual-channel models can generate two identical or completely different signals, and external signals can be connected and added to the output. The included ArbExpress software allows waveforms to be imported from any Tektronix oscilloscope or defined by standard functions, equation editor, and waveform math.
Key Features At A Glance
- Sine waveform output spanning 10 MHz to 240 MHz across the family (AFG3011C through AFG3252C)
- 14-bit arbitrary waveform generation with sample rates of 250 MS/s, 1 GS/s, or 2 GS/s depending on model
- Output amplitude up to 20 Vp-p into 50 ohm loads
- Pulse waveforms with independently variable leading and trailing edge times
- AM, FM, PM, FSK, and PWM modulation plus sweep and burst operating modes
- Single-channel and dual-channel models available across the series
- USB, GPIB, and LAN interfaces standard for ATE integration with SCPI-1999.0 and IEEE 488-2 compatibility
- 5.6 inch color TFT display with multi-language operation and front-panel USB for waveform storage
