Product Overview

The 263 is a calibrator from Keithley. Electronic calibrations are necessary for maintaining your equipment for general monitoring and testing purposes. Calibrators enable you to solve problems with your equipment on your own, on site.

Features

Coulombs Range: 20pC - 20uC
Coulombs res: 0.5fC - 500 pC
5.5 digits LED display
O/p connctr: 2-lug triaxial co
Max. Common Mode V:350Vpk
Easy pushbutton operation
Secondary calibration standard
Switch up to 200V
Specifications:

Form Factor Benchtop
DC Volts Minimum Range 200 mV
DC Volts Maximum Range 20 V
DC Volts No. of Ranges 3 QTY
DC Volts Range Steps 1/10/100
DC Volts Minimum Resolution 5 uV
DC Volts Maximum Resolution 500 uV
DC Volts Basic 1 yr accuracy 0.0175 %
DC Current Minimum Range 2 pA
DC Current Maximum Range 20 mA
DC Current No. of Ranges 11 QTY
DC Current Range Steps 1/10/100
DC Current Minimum Resolution 0.00005 pA
DC Current Maximum Resolution 500 nA
DC Current Basic 1 yr accuracy 0.15 %
Resistance Minimum Range 1 kOhm
Resistance Maximum Range 100000 MOhm
Resistance No. of Ranges 9 QTY
Resistance Range Steps 1/10/100
Resistance Basic 1 yr accuracy 0.40 %
