Agilent N1911A P-Series Power Meter 50 MHz to 40 GHz, Opt 101
Agilent N1911A P-Series Power Meter 50 MHz to 40 GHz, Opt 101
Agilent N1911A P-Series Power Meter 50 MHz to 40 GHz, Opt 101

Agilent N1911A P-Series Power Meter 50 MHz to 40 GHz, Opt 101

Shipping calculated at checkout.
Only 1 left!

Agilent N1911A P-Series Power Meter 50 MHz to 40 GHz, Opt 101

Product Overview

When used with the Agilent N192XA wideband power sensors, the Agilent N1911A power meter provides a measurement frequency range from 50 MHz to 40 GHz with an internal zero and calibration capability.

Additional Features:

  • 30 MHz video bandwidth
  • Single shot real time capture at 100 Msample/s per second
  • Key Measurements: - peak, average, peak-to-average ratio, rise time, fall time and pulse width
  • High Speed Complementary Cumulative
  • Distribution Function (CCDF) statistical analysis
  • Also compatible with the industry standard 8480 and E-series sensors (except E932x) which provide a wide dynamic range from -70 to +44 dBm, and a frequency coverage from 9 kHz to 110 GHz.
  • Zero and calibrate while connected to the DUT
  • Versatile connectivity with USB, LAN and GPIB as standard
