Agilent HP 1153A 200MHz Differential Test Probe

Agilent HP 1153A 200MHz Differential Test Probe, with accessories

Product Overview

The Keysight Agilent HP 1153A is a 1:1 FET differential probe with 200 MHz bandwidth and 3000:1 CMRR (Common Mode Rejection Ratio) at 1 MHz. The probe has an input resistance of 1 MΩ and low input capacitance of 7 pF to minimize circuit loading. Compatible with the Keysight Agilent HP 54800, 87000, 80000, 9000, and 90000 Series oscilloscopes. This probe is not compatible with Keysight Agilent HP’s 5000, 6000 or 7000 Series oscilloscope.

Additional Features:

• DC to 200 MHz bandwidth
• AutoProbe interface compatible
• ±200 V (DC + peak AC) maximum allowable input without attenuators
• 3000:1 CMRR at 1 MHz
• Low frequency reject
• Superior tolerance to ESD
• Low DC thermal drift
• Rugged construction

Versatility:

• Make Differential or Single-ended (Ground Referenced) Measurements
• Solder Down Capability
• Handheld Probing with Variable Spacing and Compliance (>8 GHz)
• Fixtured Probing

Interchangeable Tip-Clip™ Assemblies:

• Connect to a Variety of Devices
• Economical
