Fluke 291 Single-Channel Arbitrary Waveform Generator
Fluke 291 Single-Channel Arbitrary Waveform Generator
Product Overview
Fluke 291-U 1 Channel 100 MS/S Arbitrary Waveform Generator is designed to handle real world requirements by test experts. These models can easily simulate complex signals while being easy to use, compact and affordable. On multi-channel units each channel can be operated fully independently, or multiple channels can be linked using simple or complex relationships. These universal waveform generators combine many generators in one instrument. Their extensive signal simulation capabilities include arbitrary waveforms, function generator, pulse/pulse train generator, sweep generator, trigger generator, tone generator, and amplitude modulation source. Waveform Manager Plus software provides all the features needed for creation, manipulation and management of arbitrary waveforms within a single Windows based program.
1, 2, or 4 channel 100 MS/s waveform generators
100 MS/s 12-bit arbitrary waveform capability
1 M point waveform memory
40 MHz function generator capabilities using DDS (50 MHz for square waves)
10 ns pulse pattern generator
Waveform sequencing with up to 1024 segments
Unlimited waveform storage using CF memory card
Waveform Manager Plus for Windows software
USB interface in addition to RS-232 and GPIB
